借款用途与百科/Brief Introduction：

机器是转化成内服液的钢化玻璃罐的新服务，基本很好解决了往日内服液的钢化玻璃罐的不良现象治疗效果。这类的灌封机常用的塑胶板材瓶，显然不都要洗瓶机、干燥机，更不都要消毒杀菌，就可以随时灌封。这个机器全自动定位理瓶、进瓶、罐装线，罐装线量不安稳性，无漏滴，无瓶不罐装线。上盖、封膜率达到100%。此机系统品质可靠，容积小、运动不安稳性、背景噪声低，操作流程维修培训、清晰利于等优点和缺点，基本按照GMP标准的。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本参数有中速和快速路两者总产量供您抉择。Note: this model has two kinds of low speed and high-speed production for your choice.

结构特征 Characteristic

◆滤油机可广泛用于于不同易折瓶服用液测量分装和封好。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆所有电子部件部件均用着名品店牌。All electrical components adopt famous brand◆机器基本操作直观教学便于，无瓶不灌装设备，剂量*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折塑料件瓶灌封机的核心组成部分与的基本原理Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型原浆、油类液易折塑胶片瓶灌封机主要是理瓶器、理盖器、主传动装备系统软件、同步操作带开距送小瓶置、瓶子检漏装备、灌装设备平台、剔出装备、热熔连接封平台、气动系统机械化小指夹瓶平台、台达伺服发电机发电机开距上瓶平台与出瓶平台等包含。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆系统用到的原浆、油类液易折塑胶瓶、盖是一种定洁净间区的生产的，该有药袋材可证证，因为瓶身与底盖经产生和"去负责"后可之间走进灌封间。经过理盖器、理瓶器的电脑自动定项清理，移除正向底盖及瓶身底口朝下的瓶，使定项后的包材喂料有技巧地走进传输导轨中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆定向委培后胶囊液易折PVC瓶在运输单轨第二排Directional oral liquid after folding plastic bottles in conveying rail out easily

技術叁数technical parameters：

型号model	NLGFY-40	NLGFY-80
装量区间The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
密封率Hot sealing intensity	》99%
装量误差率The load error	《1.5%
脏污率damage rate	《1.0%
额定功率power	2KW	3KW
电Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
含水量 Weight	700Kg	800Kg
